Alloy Steel Pipe Fittings Manufacturer and Suppliers
Most Trusted Manufacturer of Alloy Steel Pipe Fittings, Alloy Steel Pipe Fittings, Alloy Steel Buttweld Pipe Fittings, Alloy Steel Socket Weld Pipe Fittings, Alloy Steel Threaded Forged Fittings, Alloy Steel Socket weld Pipe Fittings Exporter
Alloy Steel Eccentric Reducer Fittings, Alloy Steel Equal Tee Pipe Fittings, Alloy Steel Pipe End Cap Fittings, Alloy Steel Hex Plug Fittings, Alloy Steel Expansion Joint Fittings, Alloy Steel Swage Nipple, 90/45 Deg Long Radius Alloy Steel Elbow Manufacturer
Vasraj Stainless Steel is an ISO certified manufacturer, supplier, and exporter of supreme quality Alloy Steel Pipe Fittings. We supply these pipe fittings in several types, dimensions, sizes, forms, material grades, and specifications. Using high-grade raw materials and modern machinery, we manufacture these Alloy Steel Pipe Fittings and deliver them all across the world.
Alloy Steel Pipe Fittings are offered in diverse types including Alloy Steel Buttweld Pipe Fittings, Alloy Steel Socket Weld Pipe Fittings, Alloy Steel Threaded Forged Pipe Fittings and Alloy Steel Instrumentation Pipe Fittings, etc. In Alloy Steel, steel is alloyed with various elements to improve their strength and toughness. The improved mechanical properties provide a higher working life over a wide range of temperatures.
We are expertized in offering these Alloy Steel Pipe Fittings in both welded and seamless forms. These Pipe Fittings are best suitable for processing equipment, paper & pulp production, power generation and petrochemical industries. Our pipe fittings are available in diverse sizes and pressure ratings. Contact Us and request a free quotation.
Alloy Steel 1.5d Pipe Fittings, ASME SA234 Chrome Moly Cross Fittings Stockist, Alloy Steel 180 Deg Buttweld Fittings, Alloy Steel Gr. 90 Socket Weld Fittings, ANSI A234 Alloy Steel Pipe Fittings Manufacturer, Alloy Steel ANSI 4340 Ferrule Fittings Exporter
Alloy Steel Pipe Fittings - Quick Section Links
- Specifications for Alloy Steel Pipe Fittings
- Types of Alloy Steel Pipe Fittings
- Other Grades of Alloy Steel Pipe Fittings
- Alloy Steel Pipe Fittings Chemical Composition
- Alloy Steel Pipe Fittings Mechanical Properties
- Price List of Alloy Steel Pipe Fittings
- Alloy Steel Pipe Fittings – Industries & Applications
- Stock Availability of Alloy Steel Pipe Fittings
- Prominent Countries where we export Alloy Steel Pipe Fittings
- Cities where we export Alloy Steel Pipe Fittings
Specifications for Alloy Steel Pipe Fittings
These are the Standard specifications of Alloy Steel Pipe Fittings. We also manufacture and export any custom specification as per client’s requirement. For any custom specification Click Here to contact us.
Specifications | ASTM B 160 ASME SB 160 |
Standard | DIN, ASTM, BS and all International Standards |
Length | 3 mm to 200 mm |
Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
Type | Hex Head Bolts, Square Bolts, U bolts, Eye bolts, T bolt, Hex Bolt, Lag Bolts, Counter sunk Bolts, Hex Head nuts, Square nuts, Lock nuts, Eye nuts, wing nuts, T nuts, Panel Nuts, Coupling Nuts, Dome nuts, Acorn Nuts. |
Types of Alloy Steel Pipe Fittings
Alloy Steel 45 Degree Elbow | Alloy Steel Buttweld 45 Deg. Elbow |
Chrome Moly 45 Degree Elbow | ASME A234 Alloy Steel 45 Degree Elbow |
Alloy Steel Pipe Fittings | Chrome Moly Buttweld Fitting |
Alloy Steel Buttweld Fitting | ASTM A234 Alloy Steel Buttweld Fitting |
Alloy Steel Eccentric Reducer | Chrome Moly Eccentric Reducer |
AS Eccentric Reducer | ASTM A234 Alloy Steel Eccentric Reducer |
Alloy Steel Concentric Reducer | Alloy Concentric Reducer |
Chrome Moly Concentric Reducer | ANSI B16.9 Alloy Steel Concentric Reducer |
Alloy Steel Lateral Tee | AS Lateral Tee |
Chrome Moly Lateral Tee | ASME SA234 Alloy Steel Lateral Tee |
Alloy Steel Equal Tee | AS Equal Tee |
Chrome Moly Equal Tee | ASTM A234 Alloy Steel Equal Tee |
Alloy Steel Long Stub End | Chrome Moly Long Stub End |
ASTM A234 Alloy Steel Long Stub End | Alloy Steel Short Stub End |
Chrome Moly Short Stub End | AS Short Stub End |
MSS-SP-43 Alloy Steel Short Stub End | Alloy Steel End Cap |
Chrome Moly Gr. End Cap | AS End Cap |
ASTM A234 Alloy Steel End Cap | Alloy Steel Pipe Bend |
Alloy Steel 5D Bend | Alloy Steel 180D Bend |
Chrome Moly Pipe Bend | Alloy Steel 1D Bend |
ASTM A234 Alloy Steel U Bend | Alloy Steel Equal Cross |
Chrome Moly Equal Cross | AS Equal Cross |
Other Grades of Alloy Steel Pipe Fittings
Alloy Steel WP1 Pipe Fittings | Alloy Steel WP5 Pipe Fittings |
Alloy Steel WP9 Pipe Fittings | Alloy Steel WP11 Pipe Fittings |
Alloy Steel WP22 Pipe Fittings | Alloy Steel WP91 Pipe Fittings |
Alloy Steel Pipe Fittings Chemical Composition
Alloy Steel WP1 Pipe Fittings Chemical Composition | |||||
C, % | Mn, % | P, % | S, % | Si, % | Mo, % |
0.28 max | 0.30- 0.90 | 0.045 max | 0.045 max> | 0.10- 0.50 | 0.044-0.65 max |
Alloy Steel WP5 Pipe Fittings Chemical Composition | ||||||
C | Mn | Si | S | P | Cr | Mo |
≤0.15 | ≤0.6 | ≤0.5 | ≤0.04 | ≤0.03 | 4-6 | 0.44-0.65 |
Alloy Steel WP9 Pipe Fittings Chemical Composition | |||||||
Grade | C | Mn | Si | S | P | Cr | Mo |
A234 WP9 |
≤0.15 | ≤0.6 | 1.00 | ≤0.03 | ≤0.03 | 8-10 | 0.99-1.10 |
Alloy Steel WP11 Pipe Fittings Chemical Composition | |||||||
Grade | C | Mn | Si | S | P | Cr | Mo |
A234 WP11 |
0.05-0.2 | 0.3-0.8 | 0.5-1 | ≤0.030 | ≤0.030 | 1-1.5 | 0.44-0.65 |
Alloy Steel WP22 Pipe Fittings Chemical Composition | |||||||
Grade | C | Mn | Si | S | P | Cr | Mo |
A234 WP22 |
0.05-0.15 | 0.3-0.6 | ≤0.5 | ≤0.04 | ≤0.04 | 2-2.5 | 0.87-1.13 |
Alloy Steel WP91 Pipe Fittings Chemical Composition | |||||||
Grade | C | Mn | Si | S | P | Cr | Mo |
A234 WP91 |
0.08-0.12 | 0.3-0.6 | 0.2-0.5 | ≤0.02 | ≤0.015 | 8-9.5 | 0.85-1.05 |
Alloy Steel Pipe Fittings Mechanical Properties
Alloy Steel WP1 Pipe Fittings Mechanical Properties | |||
Tensile Strength , MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
220 min | 415 min | 20 min | 121-174 |
Alloy Steel WP5 Pipe Fittings Mechanical Properties | |||
Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % | |
415 – 585 | ≥205 | ≥20 |
Alloy Steel WP9 Pipe Fittings Mechanical Properties | ||
Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
380 min | 585 min | ≥30 |
Alloy Steel WP11 Pipe Fittings Mechanical Properties | ||
Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
Alloy Steel WP22 Pipe Fittings Mechanical Properties | ||
Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
415-585 | ≥205 | ≥20 |
Alloy Steel WP91 Pipe Fittings Mechanical Properties | ||
Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
≥590 | ≥415 | ≥20 |
Price List of Alloy Steel Pipe Fittings
Vasraj Stainless Steel is one of the most competitive suppliers of Alloy Steel Pipe Fittings products from India. Prices for Alloy Steel Pipe Fittings Products are very affordable.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Vasraj Stainless Steel maintains a stock of all standard items and can export them at the best Alloy Steel Pipe Fittings.
Alloy Steel Pipe Fittings - Industries & Applications
Our Alloy Steel Pipe Fittings are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
Stock Availability of Alloy Steel Pipe Fittings
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for Alloy Steel Pipe Fittings.
