Alloy Steel Nuts & Bolts Manufacturer and Suppliers
Most Prominent Alloy Steel Nuts & Bolts Supplier, Industrial Steel Fasteners, Alloy Steel Anchor Fasteners Manufacturer, ASME SA 194 Alloy SS Bolts, Alloy Steel Screws, ASTM A193 Alloy Steel Nuts, SS Nuts, SS Bolts, Alloy Steel Bolts & Nuts Exporter
Alloy Steel Nylock Nut, Alloy Steel Hex Bolts, Alloy SS Hex Nuts, Alloy Steel Flange Nuts, Alloy Steel Weld Nuts, Alloy Steel Dome Nut, Alloy Steel Wing Nuts, Alloy Steel Ring Nuts, Alloy Steel Counter Sunk Bolts, Alloy SS Hex Head Bolts
We are Vasraj Stainless Steel a most preferred manufacturer, supplier and exporter of a comprehensive range of Alloy Steel Nuts & Bolts. These Alloy Steel Fasteners are supplied in different types, sizes, dimensions, and specifications. With the help of modern machinery and standard raw materials, we produce these Steel Nuts & Bolts and deliver them all around the world.
Steel that can alloy with other metal elements to formed Alloy Steel. These Alloy Steel Nuts & Bolts provide excellent strength, corrosion resistance, toughness, and good mechanical properties. The low Alloy Steel Nuts & Bolts have nickel, chromium, and molybdenum, which can be hardened using only the cold working process.
Our Alloy Steel Nuts & Bolts are well appreciated for their higher working and greater strength over a wide range of temperatures. We offer different types of Alloy Steel fasteners such as Alloy Steel Hex Bolts, Alloy Steel Flange Nuts, Alloy Steel Counter Sunk Nuts, Alloy SS Hex Head Bolts, Alloy Steel Panel Nuts and more.
Alloy Steel Nuts & Bolts are highly demanded in a variety of industries notably processing industries, paper & pulp production, power generation, marine applications and more. Contact Us today to buy these fasteners at affordable prices.
Alloy Steel B7M Panel Nuts, Alloy Steel B7 Bolts, Alloy Steel B6 Nuts, Alloy Steel B16 Nuts & Bolts, Alloy Steel Gr 6 Lag Bolts Price in India, Alloy Steel 2HM Self Clinching Fasteners Stockist
Alloy Steel Nuts & Bolts - Quick Section Links
- Specifications for Alloy Steel Nuts & Bolts
- Types of Alloy Steel Nuts & Bolts
- Other Grades of Alloy Steel Nuts & Bolts
- Alloy Steel Nuts & Bolts Chemical Composition
- Alloy Steel Nuts & Bolts Mechanical Properties
- Price List of Alloy Steel Nuts & Bolts
- Alloy Steel Nuts & Bolts – Industries & Applications
- Stock Availability of Alloy Steel Nuts & Bolts
- Prominent Countries where we export Alloy Steel Nuts & Bolts
- Cities where we export Alloy Steel Nuts & Bolts
Specifications for Alloy Steel Nuts & Bolts
These are the Standard specifications of Alloy Steel Nuts & Bolts. We also manufacture and export any custom specification as per client’s requirement. For any custom specification Click Here to contact us.
Specifications | ASTM A 193 ASME SA 193 |
Standard | DIN, ASTM, BS and all International Standards |
Length | 3 mm to B6 mm |
Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
Type | Hex Head Bolts, Square Bolts, U bolts, Eye bolts, T bolt, Hex Bolt, Lag Bolts, Counter sunk Bolts, Hex Head nuts, Square nuts, Lock nuts, Eye nuts, wing nuts, T nuts, Panel Nuts, Coupling Nuts, Dome nuts, Acorn Nuts. |
Types of Alloy Steel Nuts & Bolts
Alloy Steel Hex Head Bolt & Nuts | ASTM A193 Alloy Steel Hex Head Bolt & Nuts |
Alloy Steel Square Bolt & Nuts | ASTM A193 Alloy Steel Square Bolt & Nuts |
Alloy Steel U Bolt & Nuts | Chrome Moly U Bolt & Nuts |
ASTM A193 Alloy Steel U Bolt & Nuts | Alloy Steel Eye Bolt & Nuts |
Chrome Moly Eye Bolt & Nuts | ASTM A193 Alloy Steel Eye Bolt & Nuts |
Alloy Steel T Bolt & Nuts | Chrome Moly T Bolt & Nuts |
Alloy Steel Hex Bolt & Nuts | Chrome Moly Hex Bolt & Nuts |
ASTM A193 B6 Alloy Steel Hex Bolt & Nuts | Alloy Steel Lag Bolt & Nuts |
ASTM A193 Alloy Steel Lag Bolt & Nuts | Alloy Steel Counter sunk Bolt & Nuts |
Chrome Moly Counter sunk Bolt & Nuts | ASTM A193 Counter sunk Bolt & Nuts |
Other Grades of Alloy Steel Nuts & Bolts
Alloy Steel B6 Bolt & Nut | Alloy Steel B7 Bolt & Nut |
Alloy Steel B7M Bolt & Nut | Alloy Steel B16 Bolt & Nut |
Alloy Steel 2 Bolt & Nut | Alloy Steel 2HM Bolt & Nut |
Alloy Steel 2H Bolt & Nut | Alloy Steel GR 6 Bolt & Nut |
Alloy Steel GR 7 Bolt & Nut | Alloy Steel GR 7M Bolt & Nut |
Alloy Steel Nuts & Bolts Chemical Composition
Grades | C | Mn | Si | P | S | Co | Cr |
Alloy Steel B6 | 0.15 max | 1.00 max | 1.00 max | 0.040 | 0.030 | – | 11.50-13.50 |
Alloy Steel B7 | 0.37-0.49 | 0.65-1.10 | 0.035 Max | 0.04 Max | 0.15-0.35 | 0.75-1.20 | 0.15-0.25 |
Alloy Steel B7M | 0.37-0.49 | 0.65-1.10 | 0.035 Max | 0.04 Max | 0.15-0.35 | 0.75-1.20 | 0.15-0.25 |
Alloy Steel B16 | 0.15 max | 1.00 max | 0.040 | 0.030 | 1.00 max | – | 11.50-13.50 |
Alloy Steel 2 | 0.40% min | 1.00% max | 0.040% | 0.050% | 0.40% max | – | – |
Alloy Steel 2HM | 0.40% min | 1.00% max | 0.040% | 0.050% | 0.40% max | – | – |
Alloy Steel 2H | 0.40% min | 1.00% max | 0.040% | 0.050% | 0.40% max | – | – |
Alloy Steel GR 6 | 0.15% | 1.00% | 0.04% | 0.03% | 1.00% | – | 11.5-13.5% |
Alloy Steel GR 7 | 0.37-0.49% | 0.65-1.10% | 0.04% | 0.04% | 0.15-0.035% | 0.15-0.25% | 0.75-1.20% |
Alloy Steel GR 7M | 0.37-0.49% | 0.65-1.10% | 0.04% | 0.04% | 0.15-0.035% | 0.15-0.25% | 0.75-1.20% |
Alloy Steel Nuts & Bolts Mechanical Properties
Alloy Steel B6 | ||||||
---|---|---|---|---|---|---|
Yield Rp0.2 (MPa) |
Tensile Rm (MPa) |
Impact KV/Ku (J) |
Elongation A (%) |
Reduction in cross section on fracture Z (%) |
As-Heat-Treated Condition | Brinell hardness (HBW) |
666 (≥) | 997 (≥) | 42 | 14 | 43 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 121 |
Grade | Size | Tensile ksi, min | Yield, ksi, min | Elong, %, min | RA % min |
---|---|---|---|---|---|
B7 | Up to 2-1/2 | 125 | 105 | 16 | 50 |
2-5/8 – 4 | 115 | 95 | 16 | 50 | |
4-1/8 – 7 | 100 | 75 | 18 | 50 | |
B7M | Up to 2-1/2 | 125 | 105 | 16 | 50 |
2-5/8 – 4 | 115 | 95 | 16 | 50 | |
4-1/8 – 7 | 100 | 75 | 18 | 50 | |
B16 | Up to 2-1/2 | 125 | 105 | 18 | 50 |
2-5/8 – 4 | 110 | 95 | 17 | 45 | |
4-1/8 – 7 | 100 | 85 | 16 | 45 |
Specification | Material | Nominal Size, In. | Tempering Temp. °F | Proof Load Stress, ksi | Hardness Rockwell | See Note | |
---|---|---|---|---|---|---|---|
Min | Max | ||||||
ASTM A194 Grade 2HM | Medium Carbon Steel, Quenched and Tempered | 1/4 – 4 | 1000 | 150 | 159 | 237 | 1,2,3 |
ASTM A194 Grade 2H | Medium Carbon Steel, Quenched and Tempered | 1/4 – 4 | 1000 | 175 | C24 | C38 | 1,2 |
Grades | C | Mn | P | S | Si | Ni | Cr |
Alloy Steel GR 6 | 0.15% | 1.00% | 0.04% | 0.03% | 1.00% | – | 11.5-13.5% |
Alloy Steel GR 7 | 0.37-0.49% | 0.65-1.10% | 0.04% | 0.04% | 0.15-0.035% | 0.15-0.25% | 0.75-1.20% |
Price List of Alloy Steel Nuts & Bolts
Alloy Steel Nuts & Bolts - Industries & Applications
Our Nickel Alloy Nuts & Bolts are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
Stock Availability of Alloy Steel Nuts & Bolts
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for Nickel Alloy Nuts & Bolts.
